Automatic Stroke Hydraulic Bender for Flatwise/Edgewise Bending in 3 Seconds

Name: Automatic Stroke Hydraulic Bender for FlatwiseEdgewise Bending in 3 Seconds
Brand: Suntech
Price: 1 USD

Automatic Stroke Hydraulic Bender for Flatwise/Edgewise Bending in 3 Seconds Manufactures

Brand Name : Suntech

Model Number : CB-150D

Certification : ISO

Place of Origin : Ningbo

MOQ : 1 PCS

Price : Negotiable

Payment Terms : L/C,T/T

Supply Ability : 1200PCS/Month

Delivery Time : 3-7days

Packaging Details : Plywood Case

Name : Hydraulic Bus-Bar Bender

Item No. : 06242-06247

Model : CB-150D

Bending force : 170KN-27T

Max thickness of sheet : CU/AL plate 10-12mm

Width of sheet : CU/AL plate 150-200mm

Height : 250-340mm

Weight : 20.5-70KG

Contact Now

Automatic Stroke Hydraulic Bender for Flatwise/Edgewise Bending in 3 Seconds

Industrial Hydraulic Busbar Bending Solution
This professional-grade hydraulic bus-bar bender revolutionizes metal fabrication with its dual-capacity for both flat bending (0-180°) and vertical bending (0-90°). The 20-ton hydraulic system (requires external pump, not included) delivers consistent force for processing copper/aluminum busbars from 40x10mm to 120x12mm dimensions.

Key features include:

Precision Engineering - Laser-etched angle scale with ±0.5° accuracy and adjustable limit stops ensure repeatable bends for switchgear, transformers, and solar panel installations.
Dual-Mode Operation - Quickly switch between flat bending (for parallel connections) and vertical bending (for riser applications) with the patented die-changing mechanism.
Safety First - Reinforced steel frame withstands 150% overload, while the anti-slip pedal and emergency stop button comply with OSHA standards.
Smart Compatibility - Pre-drilled mounting holes allow integration with CNC automation systems (optional), increasing production speed by 300% compared to manual bending.

Performance Data:

Bending Speed: 8-12 cycles/minute (depending on pump capacity)
Maximum Pressure: 59MBar (10,000PSI)
Weight: 298kg (portable with forklift)
Noise Level: <65dB (factory-tested)

Includes: Main unit, 6 standard dies (R5/R10/R15 for flat bending; R20/R30/R50 for vertical bending), user manual with bending force charts. Optional accessories: laser angle finder, hydraulic pump package, CNC interface module.

Specification

Item number	06245	06246	06245A	06246A
Model	SCB-100D	BCB-100A	SCB-120D	BCB-120A
Output(Mpa)	44		59
Stroke(MM)	250		320
Bending ability(MM)	40-100(Width) 4-10(Thickness)		440-120(Width) 4-12(Thickness)
Bending angle(MM)	90°<A<180°		90°<A<180°
Radius of curvature	25 times the width		25 times the width
Weight(KG)	50KG		100KG
Size(MM)	760x380x580mm		960x450x540mm

Automatic Stroke Hydraulic Bender for Flatwise/Edgewise Bending in 3 Seconds

Automatic Stroke Hydraulic Bender for Flatwise/Edgewise Bending in 3 Seconds Images
